Dimensions d 150mm D 240mm H 97mm D1≈173mm B 21mm r1,2min.1.5mm r3,4min.1.1mm Abutment dimensions da 170mm Damax.198mm ramax.1.5mm rbmax.1mm Calculation data Basic dynamic load ratingC 270kN Basic static load ratingC0 930kN Fatigue l
Dimensions d 140mm D 225mm H 90mm D1≈163mm B 20mm r1,2min.1.5mm r3,4min.1.1mm Abutment dimensions da 160mm Damax.186mm ramax.1.5mm rbmax.1mm Calculation data Basic dynamic load ratingC 238kN Basic static load ratingC0 830kN Fatigue l
Dimensions d 45mm D 90mm H 49.6mm H1 55mm D1≈57mm D2 72mm D3 95mm B 10mm C 9mm R 72mm s 32.5mm r1,2min.1mm r3,4min.0.6mm Abutment dimensions da 55mm Damax.72mm ramax.1mm rbmax.0.6mm Calculation da
Dimensions d 150mm D 250mm H 98mm D1≈183mm B 21mm r1,2min.1.5mm r3,4min.2mm Abutment dimensions da 180mm Damax.208mm ramax.1.5mm rbmax.2mm Calculation data Basic dynamic load ratingC 302kN Basic static load ratingC0 1120kN Fatigue lo
Dimensions d 35mm D 73mm H 39.6mm H1 45mm D1≈47mm D2 60mm D3 78mm B 9mm C 7.5mm R 56mm s 23mm r1,2min.1mm r3,4min.0.6mm Abutment dimensions da 45mm Damax.60mm ramax.1mm rbmax.0.6mm Calculation dat
Dimensions d 30mm D 68mm H 44mm D1≈35mm B 10mm r1,2min.1mm r3,4min.0.3mm Abutment dimensions da 35mm Damax.48mm ramax.1mm rbmax.0.3mm Calculation data Basic dynamic load ratingC 49.4kN Basic static load ratingC0 96.5kN Fatigue load l
Dimensions d 25mm D 60mm H 38mm D1≈32mm B 9mm r1,2min.1mm r3,4min.0.3mm Abutment dimensions da 30mm Damax.42mm ramax.1mm rbmax.0.3mm Calculation data Basic dynamic load ratingC 35.8kN Basic static load ratingC0 65.5kN Fatigue load li
Dimensions d 35mm D 100mm H 78.9mm H1 86mm D1≈47mm D2 72mm D3 105mm B 17mm C 12.5mm R 80mm s 23.5mm r1,2min.1.1mm r3,4min.0.6mm Abutment dimensions da 45mm Damax.72mm ramax.1mm rbmax.0.6mm Calcula
Dimensions d 35mm D 85mm H 52mm D1≈47mm B 12mm r1,2min.1mm r3,4min.0.6mm Abutment dimensions da 46mm Damax.61mm ramax.1mm rbmax.0.6mm Calculation data Basic dynamic load ratingC 76.1kN Basic static load ratingC0 153kN Fatigue load li
Dimensions d 30mm D 78mm H 49mm D1≈40mm B 12mm r1,2min.1mm r3,4min.0.6mm Abutment dimensions da 40mm Damax.55mm ramax.1mm rbmax.0.6mm Calculation data Basic dynamic load ratingC 61.8kN Basic static load ratingC0 122kN Fatigue load li
Dimensions d 110mm D 190mm H 80mm D1≈133mm B 18mm r1,2min.1.5mm r3,4min.1.1mm Abutment dimensions da 130mm Damax.154mm ramax.1.5mm rbmax.1mm Calculation data Basic dynamic load ratingC 182kN Basic static load ratingC0 585kN Fatigue l
Dimensions d 80mm D 210mm H 159.9mm H1 176mm D1≈103mm D2 155mm D3 220mm B 33mm C 27mm R 160mm s 43.5mm r1,2min.3mm r3,4min.1.1mm Abutment dimensions da 100mm Damax.155mm ramax.2.5mm rbmax.1mm Calc
Dimensions d 30mm D 62mm H 37.8mm H1 42mm D1≈37mm D2 48mm D3 65mm B 8mm C 7mm R 50mm s 21mm r1,2min.1mm r3,4min.0.3mm Abutment dimensions da 35mm Damax.48mm ramax.1mm rbmax.0.3mm Calculation data
Dimensions d 120mm D 200mm H 81mm D1≈143mm B 18mm r1,2min.1.5mm r3,4min.1.1mm Abutment dimensions da 140mm Damax.164mm ramax.1.5mm rbmax.1mm Calculation data Basic dynamic load ratingC 156kN Basic static load ratingC0 355kN Fatigue l
Dimensions d 30mm D 68mm H 38.6mm H1 44mm D1≈42mm D2 55mm D3 72mm B 9mm C 7mm R 56mm s 25mm r1,2min.1mm r3,4min.0.6mm Abutment dimensions da 40mm Damax.55mm ramax.1mm rbmax.0.6mm Calculation data
Dimensions d 55mm D 250mm H 107mm D1≈123mm B 24mm r1,2min.2mm r3,4min.1mm Abutment dimensions da 70mm Damax.120mm ramax.1.5mm rbmax.1mm Calculation data Basic dynamic load ratingC 234kN Basic static load ratingC0 550kN Fatigue load l
Dimensions d 95mm D 160mm H 67mm D1≈113mm B 15mm r1,2min.1.1mm r3,4min.1mm Abutment dimensions da 110mm Damax.130mm ramax.1mm rbmax.1mm Calculation data Basic dynamic load ratingC 125kN Basic static load ratingC0 365kN Fatigue load l
Dimensions d 50mm D 130mm H 93mm D1≈62mm B 21mm r1,2min.1.5mm r3,4min.0.6mm Abutment dimensions da 60mm Damax.88mm ramax.1.5mm rbmax.0.6mm Calculation data Basic dynamic load ratingC 199kN Basic static load ratingC0 430kN Fatigue loa
Dimensions d 100mm D 170mm H 68mm D1≈123mm B 15mm r1,2min.1.1mm r3,4min.1.1mm Abutment dimensions da 120mm Damax.140mm ramax.1mm rbmax.1mm Calculation data Basic dynamic load ratingC 127kN Basic static load ratingC0 390kN Fatigue loa
Dimensions d 85mm D 150mm H 67mm D1≈103mm B 15mm r1,2min.1.1mm r3,4min.1mm Abutment dimensions da 100mm Damax.120mm ramax.1mm rbmax.1mm Calculation data Basic dynamic load ratingC 119kN Basic static load ratingC0 325kN Fatigue load l
Dimensions d 130mm D 215mm H 89mm D1≈153mm B 20mm r1,2min.1.5mm r3,4min.1.1mm Abutment dimensions da 150mm Damax.176mm ramax.1.5mm rbmax.1mm Calculation data Basic dynamic load ratingC 178kN Basic static load ratingC0 490kN Fatigue l
Dimensions d 65mm D 140mm H 86.1mm H1 95mm D1≈82mm D2 110mm D3 145mm B 18mm C 15mm R 112mm s 45.5mm r1,2min.1.5mm r3,4min.1mm Abutment dimensions da 80mm Damax.110mm ramax.1.5mm rbmax.1mm Calculat
Dimensions d 70mm D 150mm H 95.2mm H1 105mm D1≈88mm D2 115mm D3 155mm B 19mm C 17.5mm R 112mm s 39mm r1,2min.1.5mm r3,4min.1mm Abutment dimensions da 85mm Damax.115mm ramax.1.5mm rbmax.1mm Calcula
